M13 Hercules Globular Cluster: How to Find and Observe It

What Is the M13 Hercules Globular Cluster?

M13 (NGC 6205) is a globular cluster in the constellation Hercules, containing approximately 300,000 stars packed into a sphere just 145 light-years across. It was discovered by Edmond Halley in 1714 and added to Charles Messier's catalog in 1764. At magnitude 5.8, M13 is just visible to the naked eye under pristine dark skies, appearing as a faint fuzzy star. Through binoculars it becomes a bright, unresolved patch of light. Through a telescope, it transforms into one of the most spectacular sights in the night sky — a dense swarm of stars that seems to go on forever as magnification increases. M13 is located 25,000 light-years from Earth, meaning the light you see tonight began its journey toward us during the last ice age. The cluster is about 12 billion years old, making it one of the oldest structures in our galaxy.

How to Find M13

Finding M13 is straightforward once you know the key stars to look for. The constellation Hercules is best located by first finding the bright star Vega in Lyra (the brightest star in the summer sky). Hercules lies between Vega and the bright star Arcturus in Boötes. The easiest landmark within Hercules is the Keystone — a distinctive trapezoid of four stars that forms the torso of Hercules. M13 is located on the western side of the Keystone, approximately one-third of the way from the top to the bottom along the western edge. More precisely, M13 sits between the stars Eta Herculis and Zeta Herculis. Eta Herculis marks the top of the Keystone's western side, and Zeta Herculis marks the bottom. M13 is about one degree (two full Moon widths) south of Eta Herculis, on a line connecting Eta and Zeta. In a finderscope, M13 appears as a small, fuzzy patch that looks like an out-of-focus star. For more on navigating the night sky, see our Hercules constellation guide and beginner's constellation guide.

To locate M13 with absolute precision, use a star-hopping technique. Start at the bright star Vega, move approximately 15 degrees east-southeast to find the Keystone of Hercules. The Keystone is approximately 5 degrees wide and 7 degrees tall. Identify the two westernmost stars of the Keystone: Eta Herculis (magnitude 3.5) at the top and Zeta Herculis (magnitude 2.8) at the bottom. Trace a line downward from Eta toward Zeta, and stop one-third of the way down. Centre your finderscope on this position, and M13 should appear as a small, round, fuzzy patch. If you are using a GoTo telescope like the Celestron StarSense Explorer LT 114AZ or the Sky-Watcher Virtuoso GTi, simply select M13 from the database and the telescope will slew to the correct position automatically. The cluster's brightness (magnitude 5.8) makes it one of the easiest deep-sky objects to locate — it is visible as a faint star-like point in 7x50 finderscopes from suburban skies. Under dark skies, M13 is barely visible to the naked eye as a faint star on the western edge of the Keystone.

What M13 Looks Like Through Different Telescopes

The view of M13 changes dramatically with aperture. Through 7x50 binoculars like the Celestron UpClose G2 10x50, M13 appears as a small, bright unresolved patch — detectable but showing no individual stars. Through a 60-70mm telescope at 30-50x, the cluster begins to show resolution at its edges, with a few dozen individual stars visible against the bright unresolved core. Through the StarSense Explorer LT 114AZ (114mm) at 60-80x, M13 is resolved across most of its surface, with hundreds of stars visible in chains and streams radiating from the dense core. This is where M13 becomes genuinely breathtaking — the famous "propeller" feature (three dark dust lanes near the centre) becomes visible on nights of good seeing. Through a 200mm (8-inch) Dobsonian like the Sky-Watcher Classic 200P at 150-200x, M13 is a stunning spectacle — the core is a blazing ball of unresolved light surrounded by thousands of individual stars stretching across the field of view. The propeller feature is clearly visible. Through 12-inch and larger telescopes, M13 fills the field with stars so densely packed that the centre appears three-dimensional. For recommended telescopes for deep-sky observation, see our best Dobsonian telescopes guide.

The Discovery and History of M13

M13 was discovered by the English astronomer Edmond Halley in 1714 while he was compiling a catalog of star positions. Halley noted it as a "nebulous spot" visible to the naked eye under clear conditions. Charles Messier added it to his famous catalog in 1764 as entry number 13, describing it as a "round nebula without a star" — his telescopes were not powerful enough to resolve the individual stars. It was not until 1774 that William Herschel first resolved M13 into individual stars using his large reflecting telescopes, becoming the first person to recognize that globular clusters were dense groupings of stars rather than nebulous clouds. Herschel's discovery was revolutionary — it demonstrated that what appeared to be fuzzy patches of light through smaller telescopes were actually vast collections of stars at enormous distances. Modern measurements using the Hubble Space Telescope and ground-based observatories have determined M13's distance at 25,000 light-years, its age at approximately 12 billion years, and its total stellar population at roughly 300,000 stars. The color-magnitude diagram of M13 has been extensively studied and serves as a standard reference for understanding stellar evolution in metal-poor environments.

The M13 Hercules Globular Cluster as seen by the Hubble Space Telescope. This composite image, created using observations taken between 1999 and 2006, shows the densely packed core of one of the Northern Hemisphere's finest globular clusters. Credit: NASA, ESA, and the Hubble Heritage Team (STScI/AURA)

The Science Behind M13

M13 is a globular cluster — a spherical collection of stars that orbits the Milky Way's galactic halo rather than residing in the galactic disc. Globular clusters are among the oldest structures in the universe, and M13 is estimated to be approximately 12 billion years old, forming shortly after the Milky Way itself. The cluster contains roughly 300,000 stars packed into a sphere just 145 light-years in diameter. For comparison, the nearest star to our Sun is 4.2 light-years away — if the Sun were inside M13, the nearest star would be less than 0.1 light-years away. The stars in M13 are predominantly old, metal-poor Population II stars, which give the cluster its characteristic yellowish hue in long-exposure photographs. The cluster's mass is approximately 600,000 solar masses, and it is moving through space at about 250 km per second relative to the Sun. The famous "propeller" feature — three dark dust lanes near the centre — was originally thought to be dust within the cluster, but may actually be foreground material in the Milky Way that happens to lie along our line of sight to the dense core. In 1974, the Arecibo radio telescope transmitted a message toward M13 as part of the Arecibo Message project, though the cluster is 25,000 light-years away, so the message will not arrive for approximately 22,000 years.

Observing Tips for the Best View

To get the best view of M13, follow these practical tips. Wait until the cluster is at least 40 degrees above the horizon — below that altitude, atmospheric extinction dims the fainter stars and blurs the resolution. M13 reaches its highest point in the sky around midnight in July, making this month the ideal observing window. Use averted vision (look slightly to the side of the cluster) to see more stars at the resolution threshold — the peripheral retina is more sensitive to low light levels. Start at low magnification (40-50x) to locate the cluster and appreciate its full extent, then increase magnification to 100-150x to resolve individual stars. The best magnification for resolution is approximately 20x per inch of aperture. A moonless night is essential — even a half Moon washes out the fainter stars in the cluster. M13 is bright enough to be visible from suburban skies (Bortle 5-6), but the number of resolved stars increases dramatically from dark skies (Bortle 3-4). For selecting the best telescope for this target, consider the FirstScope for casual views or the Sky-Watcher Heritage 130P for serious resolution at a budget price.

Recommended Equipment for Observing M13

To get the best views of M13, choose your equipment with care. For binocular observers, a 10x50 or 15x70 binocular shows M13 as a bright unresolved patch — enough to appreciate its brightness but not enough to resolve individual stars. A 70mm telescope at 30-50x begins to resolve the outer edges of the cluster. For serious resolution, a 114mm telescope like the Celestron StarSense Explorer LT 114AZ at 60-80x shows stars across most of the cluster's surface. The best views come from a 150mm or 200mm Dobsonian at 100-150x — the cluster fills the field with hundreds of individual stars. A 2-inch wide-field eyepiece (30-40mm) at low power provides a stunning context view of the cluster against the surrounding Hercules star field. A 9mm or 10mm eyepiece at 120-150x provides the best balance of resolution and brightness for studying the core and the propeller feature. An O-III or UHC filter does not improve globular cluster views — these filters are designed for emission nebulae, not clusters. For the best experience, observe M13 from a dark sky site using a 150mm or larger telescope with a comfortable observing chair. For recommended telescopes for this type of viewing, see our best Dobsonian telescopes guide.

Other Objects in the Hercules Region

While M13 is the crown jewel of Hercules, the constellation contains several other deep-sky objects worth visiting during the same observing session. M92 is another globular cluster in Hercules, located about 6.5 degrees north of M13. It is often overlooked because of its proximity to the more famous M13, but M92 is a fine object in its own right — magnitude 6.4, spanning 11 arcminutes, and well-resolved in 150mm telescopes. NGC 6207 is a small spiral galaxy located just 28 arcminutes northeast of M13 — it appears as a faint, elongated smudge in 200mm telescopes, a challenging target that shares the same field as the globular cluster at low magnification. NGC 6229 is another globular cluster in Hercules, fainter and more compact than M13, visible in 150mm telescopes as a small unresolved patch. IC 4617 is a very faint galaxy located just 6 arcminutes from M13's core — an extreme challenge that tests both telescope quality and observing skill. The Hercules region also contains several double stars worth observing, including Alpha Herculis (Ras Algethi), a beautiful red giant and blue companion pair, and Delta Herculis, a close double star that is an excellent test of telescope resolution. For more constellation-level guides, see our Hercules constellation guide.

Photographing M13

M13 is an excellent target for beginner astrophotographers. Its brightness means it can be captured with relatively short exposures, and its small angular size (20 arcminutes, about two-thirds the diameter of the full Moon) means it frames nicely even with longer focal lengths. For DSLR astrophotography, a 200mm or longer lens on a tracking mount can capture M13 with 30-second exposures at ISO 1600. Through a telescope, a 1000mm focal length at f/10 produces a well-framed image with 60-second exposures. For planetary camera capture (lucky imaging), take a 90-second video at high frame rate through a 6-inch or larger telescope and stack the best frames to reveal hundreds of individual stars. M13's position in the summer sky means it is accessible from most Northern Hemisphere observing sites, and it is circumpolar from latitudes above 40 degrees north. For more on getting started, see our astrophotography for beginners guide.

M13 vs Other Globular Clusters: How It Compares

M13 is often described as the finest globular cluster in the northern sky, but how does it compare to other great globulars? Omega Centauri (NGC 5139) in the southern constellation Centaurus is by far the largest and brightest globular cluster in the entire sky, containing approximately 10 million stars compared to M13's 300,000. Omega Centauri spans 36 arcminutes (larger than the full Moon) and is visible to the naked eye as a 3.7-magnitude star-like object. Observers at latitudes south of 40 degrees north can see it from the Southern Hemisphere or from the southernmost United States. M22 in Sagittarius is another fine globular cluster, magnitude 5.1 and spanning 24 arcminutes, located near the galactic bulge in one of the richest Milky Way star fields. M5 in Serpens is often considered the third-best northern globular after M13 and M22, magnitude 5.7 with a dense core and numerous variable stars. M92 in Hercules, M15 in Pegasus, and M2 in Aquarius are also excellent globular clusters that reward observation with large telescopes. Each has its own character — M13's combination of brightness, resolution, and the famous propeller feature makes it the best all-round choice for Northern Hemisphere observers, but exploring the others reveals the diversity of these ancient star cities.

M13 Observing Log: What to Look for at the Eyepiece

When you centre M13 in your eyepiece for the first time, work through this observing sequence to extract the most detail. At low power (40-50x), the cluster appears as a bright, round patch of light against the surrounding star field. Note the cluster's position relative to the Keystone stars — it should be about one-third of the way down the western side. At medium power (80-100x), individual stars begin to resolve, particularly at the edges of the cluster. Look for the characteristic "chains" of stars that seem to radiate outward from the centre. At high power (120-150x), the core of the cluster is a dense, unresolved blaze of light surrounded by hundreds of pinpoint stars. Search for the propeller feature — three dark lanes converging at the centre. On nights of good seeing, these appear as thin, dark wedges cutting into the bright core. The propeller is visible in 150mm telescopes and becomes increasingly distinct with larger apertures. Try different magnifications — each power reveals different aspects of the cluster, from the wide-field context at 40x to the intimate core detail at 150x. Record your observations in a log, noting the telescope, eyepiece, magnification, and sky conditions. Over multiple sessions, you will notice that M13 looks different on different nights, depending on atmospheric transparency and seeing.

Challenges and Targets Within M13

For experienced observers, M13 offers several observational challenges. The propeller feature — three dark dust lanes converging near the cluster's core — is the most famous challenge. It requires a 150mm telescope, good seeing, and careful attention to be detected. In 200mm and larger telescopes, the propeller becomes a distinct feature that adds depth to the cluster's appearance. Resolving stars across the core of M13 is another challenge — in smaller telescopes, the core remains an unresolved blaze of light. A 200mm telescope at 200x begins to resolve individual stars even in the core region, while a 300mm telescope at 300x resolves the entire cluster into individual stars. Detecting the central concentration — the brightness gradient from the cluster's edge to its core — is a test of your observing technique and sky quality. The faintest stars visible in M13 also serve as a test of your telescope's limiting magnitude. Use the cluster's well-calibrated stellar population to estimate the faintest star you can detect with your setup. This is a practical way to measure your telescope's performance under your specific sky conditions. For more observing challenges, see our M57 Ring Nebula guide.

Another advanced challenge is detecting the subtle colour differences between stars in M13. While most stars appear white through the eyepiece, the cluster contains red giants that show a faint yellowish or orange tint in larger telescopes. These red giants are among the brightest stars in the cluster and stand out against the predominantly white population of main-sequence stars. The brightest red giant in M13, designated as variable star V11, has a visual magnitude of approximately 11.9 and a distinct orange hue that is visible in 200mm and larger telescopes. Identifying these coloured stars adds an extra dimension to observing M13 and connects your visual observation with the cluster's stellar population. The cluster also contains a number of variable stars, though detecting brightness variations requires systematic observation over weeks and months. For dedicated variable star observers, M13 provides a rich field of study with dozens of variables ranging from 11th to 14th magnitude.
